54 DIA Heavy Duty Belt Drive Exhaust Fan - Less Drive Package"
Item: Exhaust Fan,Type: Heavy Duty Belt Drive Less Drive Package, Blade Dia.: 54", CFM Range:
33,602 To 50,124, Exhaust/Supply Fan Motor HP: 3 To 10, Drive Package Included: No, Max. Ambient Temp. (F): 104, Width (In.): 60, RPM Range: 480 To 716, Height (In.): 60, Bearing Type:
Regreasable Cast Pillow Block, Max. Depth (In.): 33-1/2, Venturi Clearance Dia. (In.): 55, Venturi Depth (In.): 6-1/2, Flange Depth (In.): 2, Mounting Position: Horizontal Or Vertical, Frame Material: Galvanized Steel, Propeller Material: Cast Aluminum, Number Of Blades: 6, Bearing Size (In.): 1-1/2, Shaft Dia. (In.): 1-1/2,Requires: Wall Collar And Shutter For New Installation(Not Included), In Bulk, Origin:USA
33,602 To 50,124, Exhaust/Supply Fan Motor HP: 3 To 10, Drive Package Included: No, Max. Ambient Temp. (F): 104, Width (In.): 60, RPM Range: 480 To 716, Height (In.): 60, Bearing Type:
Regreasable Cast Pillow Block, Max. Depth (In.): 33-1/2, Venturi Clearance Dia. (In.): 55, Venturi Depth (In.): 6-1/2, Flange Depth (In.): 2, Mounting Position: Horizontal Or Vertical, Frame Material: Galvanized Steel, Propeller Material: Cast Aluminum, Number Of Blades: 6, Bearing Size (In.): 1-1/2, Shaft Dia. (In.): 1-1/2,Requires: Wall Collar And Shutter For New Installation(Not Included), In Bulk, Origin:USA
$1,200.00
54 DIA Heavy Duty Belt Drive Exhaust Fan - Less Drive Package"—
$1,200.00
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Item: Exhaust Fan,Type: Heavy Duty Belt Drive Less Drive Package, Blade Dia.: 54", CFM Range:
33,602 To 50,124, Exhaust/Supply Fan Motor HP: 3 To 10, Drive Package Included: No, Max. Ambient Temp. (F): 104, Width (In.): 60, RPM Range: 480 To 716, Height (In.): 60, Bearing Type:
Regreasable Cast Pillow Block, Max. Depth (In.): 33-1/2, Venturi Clearance Dia. (In.): 55, Venturi Depth (In.): 6-1/2, Flange Depth (In.): 2, Mounting Position: Horizontal Or Vertical, Frame Material: Galvanized Steel, Propeller Material: Cast Aluminum, Number Of Blades: 6, Bearing Size (In.): 1-1/2, Shaft Dia. (In.): 1-1/2,Requires: Wall Collar And Shutter For New Installation(Not Included), In Bulk, Origin:USA
33,602 To 50,124, Exhaust/Supply Fan Motor HP: 3 To 10, Drive Package Included: No, Max. Ambient Temp. (F): 104, Width (In.): 60, RPM Range: 480 To 716, Height (In.): 60, Bearing Type:
Regreasable Cast Pillow Block, Max. Depth (In.): 33-1/2, Venturi Clearance Dia. (In.): 55, Venturi Depth (In.): 6-1/2, Flange Depth (In.): 2, Mounting Position: Horizontal Or Vertical, Frame Material: Galvanized Steel, Propeller Material: Cast Aluminum, Number Of Blades: 6, Bearing Size (In.): 1-1/2, Shaft Dia. (In.): 1-1/2,Requires: Wall Collar And Shutter For New Installation(Not Included), In Bulk, Origin:USA
