Reversing Contactor 3-Pole Coil Voltage:120VAC 50/60Hertz 50Amp 40HP 200-600 VAC
Reversing Contactor, 3-Pole, 50/60Hertz, Coil Voltage:120 VAC ,50 Amps, Contactor Application:Motor Control Resistive Load, Power Pole Contact Composition:3 No, Auxiliary Contact Composition:1 No 1 NC, Motor Power HP (Ul/CSA) 40 HP at 575/600 VAC 50/60Hz for 3 Phase Motors, 40 HP at 460/480 VAC 50/60Hz for 3 Phase Motors,15 HP at 230/240 VAC 50/60Hz for 3 Phase Motors,15 Hp at 200/208 VAC 50/60Hz for 3 Phase Motors,7.5 HP at 230/240 VAC for 1 Phase Motors,3 HP at 115 VAC 50/60Hz for 1 Phase Motors, Mounting Style:Din Rail Mount,Operating Temperature Range:-40 to 70Deg.C., Terminal Type:Screw Clamp, Series:LC2, Range:Tesys, Weight:4.10 Pounds,Dims:165mm Length X 127mm width X 142mm Depth,(Made In France)Mfg/Box,Additional TESYS-940958
$97.50
Original: $325.00
-70%Reversing Contactor 3-Pole Coil Voltage:120VAC 50/60Hertz 50Amp 40HP 200-600 VAC—
$325.00
$97.50Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Reversing Contactor, 3-Pole, 50/60Hertz, Coil Voltage:120 VAC ,50 Amps, Contactor Application:Motor Control Resistive Load, Power Pole Contact Composition:3 No, Auxiliary Contact Composition:1 No 1 NC, Motor Power HP (Ul/CSA) 40 HP at 575/600 VAC 50/60Hz for 3 Phase Motors, 40 HP at 460/480 VAC 50/60Hz for 3 Phase Motors,15 HP at 230/240 VAC 50/60Hz for 3 Phase Motors,15 Hp at 200/208 VAC 50/60Hz for 3 Phase Motors,7.5 HP at 230/240 VAC for 1 Phase Motors,3 HP at 115 VAC 50/60Hz for 1 Phase Motors, Mounting Style:Din Rail Mount,Operating Temperature Range:-40 to 70Deg.C., Terminal Type:Screw Clamp, Series:LC2, Range:Tesys, Weight:4.10 Pounds,Dims:165mm Length X 127mm width X 142mm Depth,(Made In France)Mfg/Box,Additional TESYS-940958
